Max. layout area (X/Y/Z)

300 X 300 X 50 mm with 50 mm clearance multiple PCB can be place for drilling and routing

Max. material size (X/Y/Z)

300 X 300 X 50 mm

Mechanical resolution (X/Y)

0.01 mm

Repeatability

0.03 mm

Precision of front-to-back alignment

0.03 mm

Milling spindle

Up to 0 to 60,000 rpm to drill 0.3 mm 60k rpm is required

Tool change

Manual

Tool holder

3.175 mm (1/8”)

Milling width adjustment

Manual, with software-supported measurements

Drilling speed

120 holes/min

Dimensions (W x H x D)

600 X 600 X 600 mm

Travel speed (X/Y)

166 mm /sec

Weight

For Prototyping and Routing high weight is required for stability

Power supply

230 V

Controller

Indus Controller

Options and accessories

Dust extraction unit; protective housing

Environmental conditions

Atmospheric Temperature

Other Specification

Auto Leveling sensor is included

Spindle Type

Water cooled Inbuilt motor Facility to regulate the rpm in spindle and for cooling water cooling arrangement is provided

Mechanical drive

Facility of Ball Screw for precise and high in cost compare to harden rods

Wireless control & wideband RF detector with Scan table facility

• 7” inch Touch screen with GUI control
• HDMI port facility FOR big screen
• 160mm PTFE SCAN Table
• Thickness of scan table 25mm
• RF detector +20dbm to -50dBm
•50ohm port for any antenna and RF device
•Weight handling capacity 4.5kg with rotation controller
•0 to 360 deg rotation resolution (5.4 deg /3.6deg/1.8deg)
•50X-1000X Handheld Digital Zoom Microscope Endoscope Magnifier
•TIME Vs deg Vs absolute power for RF antenna
•Frequency up to 8GHz
•Height adjustment facility
